Cisco Type 7 Password Decrypt / Decoder / Cracker Tool

Written by Administrator. Posted in Cisco Routers - Configuring Cisco Routers

4.03305785124 1 1 1 1 1 Rating 4.03 (121 Votes)
Cisco Type 7 Password Decrypt / Decoder / Cracker Tool - 4.0 out of 5 based on 121 votes

The Firewall.cx Cisco Password Decoder Tool (see below) provides readers with the ability to decrypt 'Type 7' cisco passwords.

advert-languard-850x150v1

For security reasons, we do not keep any history on decoded passwords.

Enter Your Encrypted Password Below:

Encrypted Password:

Decrypted Password:


To use this tool, simply copy & paste your 'type 7' password in the provided field below and click on the 'Submit' button. The system will then process and reveal the text-based password. For security reasons, our system will not track or save any passwords decoded.

Note: If your a Network Engineer or Administrator, be sure to check out our highly recommended Web Monitoring/Proxy solutionWeb Monitoring/Proxy solution that includes:

  • Realtime Monitoring of which files users can download
  • Phishing site protection
  • Complete Internet access control
  • Automatically filter & limit web browsing and much more


More Information On Cisco Passwords and Which can be Decoded

Back in late 1995, a non-Cisco source had released a program that was able to decrypt user passwords (and other type of passwords) in Cisco configuration files.

This new program was a major headache for Cisco since most users were relying on Cisco's equipment for their repulation of strong encryption and security capabilities. What users were not aware was that there are two different type of encryption mechanisms used by Cisco's IOS, one which was reversable (Type 7 Passwords) and one which is not (Type 5).

Even until today, administrators and users still make use of the weaker Type 7 passwords, mainly because they aren't aware that these passwords can be decrypted.

Knowing what Can and cannot be decrypted

It is important to understand that only the following type of passwords are able to be decrypted. Thefollowing examples show which common areas Type 7 passwords are used in Cisco equipment:

User Passwords

Used to create users with different privilege levels on Cisco devices.

username chris privilege 15 password 7 02000D490E110E2D40000A01

 Enable Password

Used to gain elevated access on the Cisco device.

enable password 7 01150F165E1C07032D

 Access Point SSID Keys

Used to configure the SSID key on a Cisco wireless access point:

dot11 ssid private
   vlan 1
   authentication open
   authentication key-management wpa
   guest-mode
   mbssid guest-mode
   infrastructure-ssid optional
   wpa-psk ascii 7 01150F165E1C07032D

If wpa-psk ascii 0 is used then the ascii text that follows is clear text and its not encrypted.



Encryption Methods Cannot be Decrypted

As opposed to Type 7 Passwords which can easily be decrypted, Secret 5 passwords cannot be decrypted as the password has ben hashed with MD5. This is also the recommened way of creating and storing passwords on your Cisco devices.

Following are a number of examples where Secret 5 passwords can and should be used:

User Passwords

username chris privilege 15 secret 5 $1$KNaN$SCe/xMbtBEe6ch5d2bq5J.

Enable Password

enable secret 5 $1$2UjJ$cDZ05dfEGA7mHfE4RSbWiQ.



Unfortunately Access Point SSID Keys do not support Type 5 passwords. This means that any passwords configured into the access point should be stored in a safe place.

 We trust the information was valuable and hope users will stop using Type 7 Passwords in mission critical equipment.
